Quick Details

  • Condition: New
  • Flow: 50L/min~200L/min
  • Working Pressure: 0.5Mpa
  • Place of Origin: Chongqing, China (Mainland)
  • Brand Name: Yuneng
  • Model Number: Tap Changer Oil Filtration YL
  • Usage: Tap Changer Oil Filtration, Tap Changer Oil Filtration
  • Voltage: Customer's Requirement
  • Power(W): 1.1KW
  • Dimension(L*W*H): Refer to actual data
  • Weight: 100KG
  • Certification: ISO CE BV
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Application: Tap Changer Oil Filtration
  • Structure Material: Carbon steel
  • Oil pump: Gear pump
  • Filters: Can be 1-5 stages as you need
  • Filtration precision: 10 micron
  • Function: Particles-removal
  • Type: Simple
  • Price: Lower
  • Color: Any color

Packaging & Delivery

Packaging Details Iron sheet case or wooden case/Tap Changer Oil Filtration
Delivery Time Shipped in 15 days after payment

Top Sale Tap Changer Oil Filtration Machine for Sale

Product Description



Top Sale Tap Changer Oil Filtration Machine for Sale Feature:



Top Sale Tap Changer Oil Filtration Machine for Sale is suitable to filter various impurities in insulating oil, turbine oil, mechanical oil, hydraulic oil 1-5 or more multi-stage filtration acceptable, filters can be wash / clean to reuse.



Filters choice diversified according to your oil and usage.



Top Sale Tap Changer Oil Filtration Machine for Sale is replacement for the frame-pressurized oil filling machine. It is simple in structure and easy to operate with low price.



For high-quality oil recondition machine as vacuum oil filling machine, please search our ZJA, ZJB, JZ, ZJC, JT, DYJC, KYJ… We have full series from low to high for your choice.



Top Sale Tap Changer Oil Filtration Machine for Sale

Parameters:



Parameter

Type

Unit

YL-50

YL-80

YL-100

YL-150

YL-200

Flow Rate

L/min

50

80

100

150

200

Motor Power

KW

1.1

1.5

2.2

3

4.4

Inlet/Outlet Diameter

mm

32/25

38/32

44/38

48/44

64/48

Weight

Kg

100

120

150

200

260

Working Pressure

Mpa

≤0.5Mpa

Power Supply



50Hz380V 3-Phase 4-Wire (or as requested)

Filtering accuracy

µm

≤5

Delivery lift

m

≥15



Top Sale Tap Changer Oil Filtration Machine for Sale
 Photo for Reference









Company Information

Founded in 1997, our company Yuneng has been specialized in designing and manufacturing a series of oil purifier for nearly 20 years, such as transformer oil purifier, air pumping unit, dry air generator, turbine oil purifier, lubricating oil purifier, fire-resistance oil purifier, (EHC oil) , waste oil regeneration machine and etc. The proud history makes Yuneng top supplier in oil purification field in China.

We are also the supplier of the Big Transformer Company TBEA in India, hope we could also be your supplier in the near future.


If you are interested in our products, please get back to me for more details.Thank you.




Packaging & Shipping







Our Services
Our products warranty: One year guarantee for product quality. (People damaged parts should be charged).

Lifelong maintenance and spare parts supply.

Free design of fixtures as customers required.

On site staff training for installation and operation of the machine is available.



 Contact us to get best solution for your oils



Yuneng products list:

1. Insulation Oil filling machine:

ZJA Ultra-high Transformer / Insulation Oil filling machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)

ZJA High-vacuum Transformer / Insulation Oil filling machine (110KV-500KV project)) (2 stage vacuum)

ZJB Transformer / Insulation Oil filling machine (≤110KV) (one stage vacuum)

ZJ Vacuum Pumping machine (extract vacuum, dry transformer)

GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors…).

JZ OLTC (on-load tap changer) online Oil filling machine

Quantitative oil injection machine (customized product)



2. Turbine Oil filling machine:

JT coalescing dehydration oil filling machine (dehydration by special filters)

DYJC online turbine oil filling machine (dehydration by special filters and vacuum system)

ZJC-T vacuum oil filling machine for turbine oil (dehydration by vacuum system)



3. Lubricating Oil filling machine:

ZJC-R vacuum Oil filling machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)

ZJC-M Oil filling machine for OCS. (oil with high viscosity 22-320cst at 40°C)



4. Other kinds of oil filling machine:

KYJ fire-resistance oil filling machine (EHC oil)

LY plate-frame pressure oil filling machine (simple, paper filtration)

YL Top Sale Tap Changer Oil Filtration Machine for Sale
 (simple, cheap)



5. Waste oil regeneration machine (by chemicals or by high temperature distillation)

YNZSY used oil filling machine (by chemicals)

YNZSY-LTY used tire oil filling machine (by chemicals)

Waste oil distillation machine



6. Oil tester/ analyzer:

Dielectric oil breakdown strength tester

Water content tester

Inline Digital Flow Meter and Totalizer

Viscosity analyzer

Flash point analyzer (close cup)

Flash point analyzer (open cup)

Interfacial tension analyzer

Gas chromatograph
